Powerbuilt Air Compressor 24L 2Hp Direct Drive

Powerbuilt AC2420 Air Compressor 24L 2Hp Direct Drive

by Powerbuilt
$397.26incl. GST

Notify me when back in stock

100% Secure payments
Apple Pay Google Pay PayPal VISA Mastercard shop
Nationwide delivery · NZ
Free on orders over $200. Heavy or bulky items may carry a freight charge.
Price match guarantee
Found a better price elsewhere? We'll beat it.

Overview

Product details

The Powerbuilt AC2420 Air Compressor 24L 2Hp Direct Drive is built for tradespeople, construction sites, farm workshops across New Zealand. Backed by a 1 Year Warranty, the AC2420 is supported for professional workshop and trade use.

Key Features

  • Compact, portable light weight 24L compressor for the home workshop
  • Copper wound 2Hp motor with thermal overload, heavy duty cast iron cylinder
  • Fully adjustable pressure with onboard regulator
  • Extra wide, stable feet for increased stability and stable transportation
  • 200 L/min (7CFM) displacement
  • 120 L/min (4.24CFM) free air @ 90PSI
  • Twin ARO couplers for multiple tools
  • Onboard regulator with twin ARO couplers for multiple tools
  • The best compressor is the right compressor for the job, but its important to allow for growth for your future and select a compressor for years of trouble-free operation.
  • With the pump coupled directly to the 2800 RPM motor these units have a duty cycle of 30% or where a compressor is required to run for no more than 10mins of continuous pumping.

Key Specifications

  • 1 Year Warranty
  • Gross weight: 24.0kg
  • Barcode / GTIN: 4710025136207

Suitable for: tradespeople, construction sites, farm workshops

Part No: AC2420 | Brand: Powerbuilt | Weight: 24.0kg

Related machinery: Powerbuilt AC10030 100L 3.0Hp Air Compressor - Belt Drive · Powerbuilt AC5065P 50L 6.5Hp Air Compressor (Lifan Engine) - · Powerbuilt TLS0050FW 50cm High Velocity Floor/Wall/Ceiling Fan · Powerbuilt TLS0076F 76cm High Velocity Floor Fan

Your questions answered

FAQs

What can I run on the AC2420?
Tyres, blow guns, nailers, an air ratchet and short runs with an impact wrench. It is a compact home workshop compressor with a cast iron cylinder and an onboard regulator, so you can set the pressure a nailer wants and leave it.
How much air does the AC2420 deliver?
200 litres a minute displacement, which is 120 litres a minute, or 4.2 CFM, of free air at 90 PSI. That covers nailers, ratchets and blow guns comfortably and an impact wrench in bursts. It is not enough for a spray gun or a sander running continuously.
How long does the tank take to fill?
A couple of minutes from empty. It delivers 200 litres a minute displacement, so top ups between tools are quick.
Can it run continuously?
Not for long. Direct drive pumps run at motor speed, 2,800 rpm, so this unit has a 30% duty cycle: about 10 minutes of pumping in any 30. For continuous tools look at the belt drive AC10030.
Does it need oil changes?
Yes. It is an oil-lubricated pump, which is why it runs quieter and cooler than an oil-less unit. Check the sight glass before each use and change the oil after the first 20 hours, then every 100 hours or once a season. Drain the tank after use.
What plug does it need?
A standard 10 amp household plug. The 2 HP motor has thermal overload protection.
How heavy is it and is it portable?
24kg on wide, stable feet with a top handle. One person carries it short distances.
What fittings does it come with?
ARO style quick connect couplers, which are the common standard in New Zealand. Twin outlets mean two tools can be connected at once. Any air hose with an ARO plug clicks straight on. If your existing tools are Nitto, an adaptor sorts it.

More in this category

Shop all Air Compressors NZ
Powerbuilt Air Compressor 3L 900W Oil Less Powerbuilt AC03900X Air Compressor 3L 900W Oil Less $316.17 Powerbuilt 50L 6.5Hp Air Compressor (Lifan Engine) Powerbuilt AC5065P 50L 6.5Hp Air Compressor (Lifan Engine) - $1,858.47 Powerbuilt 100L 3.0Hp Air Compressor - Belt Drive Powerbuilt AC10030 100L 3.0Hp Air Compressor - Belt Drive $1,342.43 Powerbuilt Air Compressor 50L 2900W Oil Less Powerbuilt AC5014502X Air Compressor 50L 2900W Oil Less $858.40 Powerbuilt Air Compressor 40L 1800W Oil Less Powerbuilt AC409002X Air Compressor 40L 1800W Oil Less $721.63 Powerbuilt Air Compressor 24L 1450W Oil Less Powerbuilt AC241450X Air Compressor 24L 1450W Oil Less $460.70 Powerbuilt 3pc Air Compressor Bundle Powerbuilt KITAIR10 3pc Air Compressor Bundle $414.14
